Sonar BR-2906
| Type: |
All-mode HF Linear Amplifier |
| Frequency Range: |
25-50 MHz |
| Voltage: |
12-13.8 VDC |
| Current Drain: |
Max ?? A |
| Drive power: |
1-15 W |
| Maximum Power output: |
175 W |
| Impedance: |
50 ohms, 2x SO-259 |
| Dimensions (W*H*D): |
2 x 6 x 8 inches |
| Weight: |
3 lbs |
| Manufactured: |
1969-197x |
| Other: | Sonar_BR-2906_top
|
| Related Documents: |
Manual (1.3 MB) |
 |
